PRE-ASSEMBLED 24" SEWAGE KITS
93024: 1/2 HP 24" SEWAGE KIT
Cast Iron Pump Construction
CUSTOM KITS AVAILABLE UPON REQUEST
PUMP FEATURES
-
93501 has a 10' power cord / 93507 has a 25' power cord
-
Continuous duty, thermally protected - split capacitor motor
-
Pumps will lift water up to 25' of vertical height
-
Rugged cast iron construction
-
Easily handles 2" solids
-
Large 2" discharge for high capacity pumping
-
Thermoplastic, non-clogging vortex impeller
BASIN FEATURES
-
Tough polyethylene construction
-
Gasket sealed liquid and airtight cover with 8 bolts
-
2” discharge and vent
-
Built-in anti float collar prevents basin from floating
-
Molded torque stops prevent pump from turning
-
Integrated 360° lifting handle
-
45 gallon capacity
BASIN COVER
-
18” Premium cover
-
18” Premium split lid cover
CHECK VALVE FEATURES
-
Full flow design - 99529
-
Heavy duty rubber boots
-
Stainless steel clamps
-
Full flow design
-
Weighted flapper valve
-
2" connections
Technical Specifications
HORSEPOWER | 1/2 |
AMPS | 7.6 |
CONSTRUCTION | Cast Iron |
SWITCH TYPE | Tethered |
DISCHARGE SIZE | 2“ |
DISCHARGE TYPE | Side |
CORD LENGTH | 93501 - 10’ / 93507 - 25’ |
SOLIDS HANDLING | 2” |
IMPELLER TYPE | Thermoplastic, Non-Clogging Vortex |
SWITCH ON POINT | 16“ |
SWITCH OFF POINT | 8” |
LIQUID TEMP. RANGE | 35° F - 120° F |
PUMPS DOWN TO | 3” From Surface When Used As Utility |
WARRANTY | 1 Year |
OPTIONAL ACCESSORIES
93026: 1/2 HP 24" SEWAGE KIT
Cast Iron Pump Construction
CUSTOM KITS AVAILABLE UPON REQUEST
PUMP FEATURES
-
93511 has a 10' power cord / 93525 has a 25' power cord
-
Continuous duty, thermally protected - split capacitor motor
-
Pumps will lift water up to 25' of vertical height
-
Rugged cast iron construction
-
Easily handles 2" solids
-
Large 2" discharge for high capacity pumping
-
Thermoplastic, non-clogging vortex impeller
BASIN FEATURES
-
Tough polyethylene construction
-
Gasket sealed liquid and airtight cover with 8 bolts
-
2” discharge and vent
-
Built-in anti float collar prevents basin from floating
-
Molded torque stops prevent pump from turning
-
Integrated 360° lifting handle
-
45 gallon capacity
BASIN COVER
-
18” Premium cover
-
18” Premium split lid cover
CHECK VALVE FEATURES
-
Full flow design - 99529
-
Heavy duty rubber boots
-
Stainless steel clamps
-
Full flow design
-
Weighted flapper valve
-
2" connections
Technical Specifications
HORSEPOWER | 1/2 |
AMPS | 7.6 |
CONSTRUCTION | Cast Iron |
SWITCH TYPE | Vertical |
DISCHARGE SIZE | 2“ |
DISCHARGE TYPE | Side |
CORD LENGTH | 93511 - 10’ / 93525 - 25’ |
SOLIDS HANDLING | 2” |
IMPELLER TYPE | Thermoplastic, Non-Clogging Vortex |
SWITCH ON POINT | 9“ |
SWITCH OFF POINT | 3” |
LIQUID TEMP. RANGE | 35° F - 120° F |
PUMPS DOWN TO | 3” From Surface When Used As Utility |
WARRANTY | 1 Year |
OPTIONAL ACCESSORIES
93082: 1/2 HP 24" SEWAGE KIT
Cast Iron Pump Construction
CUSTOM KITS AVAILABLE UPON REQUEST
PUMP FEATURES
-
93781 has a 10' power cord
-
Continuous duty, thermally protected - split capacitor motor
-
Pumps will lift water up to 25' of vertical height
-
Rugged cast iron construction
-
Easily handles 2" solids
-
Large 2" discharge for high capacity pumping
-
Thermoplastic, non-clogging vortex impeller
BASIN FEATURES
-
Tough polyethylene construction
-
Gasket sealed liquid and airtight cover with 8 bolts
-
2” discharge and vent
-
Built-in anti float collar prevents basin from floating
-
Molded torque stops prevent pump from turning
-
Integrated 360° lifting handle
-
45 gallon capacity
BASIN COVER
-
18” Premium cover
-
18” Premium split lid cover
CHECK VALVE FEATURES
-
Full flow design - 99529
-
Heavy duty rubber boots
-
Stainless steel clamps
-
Full flow design
-
Weighted flapper valve
-
2" connections
Technical Specifications
HORSEPOWER | 1/2 |
AMPS | 12 |
CONSTRUCTION | Stainless Steel / Cast Iron |
SWITCH TYPE | Tethered |
DISCHARGE SIZE | 2“ |
DISCHARGE TYPE | Side |
CORD LENGTH | 15’ |
SOLIDS HANDLING | 2” |
IMPELLER TYPE | Thermoplastic, Non-Clogging Vortex |
SWITCH ON POINT | 17“ |
SWITCH OFF POINT | 9” |
LIQUID TEMP. RANGE | 35° F - 120° F |
PUMPS DOWN TO | 3” From Surface When Used As Utility |
WARRANTY | 1 Year |
OPTIONAL ACCESSORIES
93084: 1/2 HP 24" SEWAGE KIT
Cast Iron Pump Construction
CUSTOM KITS AVAILABLE UPON REQUEST
PUMP FEATURES
-
93782 has a 10' power cord
-
Continuous duty, thermally protected - split capacitor motor
-
Pumps will lift water up to 25' of vertical height
-
Rugged cast iron construction
-
Easily handles 2" solids
-
Large 2" discharge for high capacity pumping
-
Thermoplastic, non-clogging vortex impeller
BASIN FEATURES
-
Tough polyethylene construction
-
Gasket sealed liquid and airtight cover with 8 bolts
-
2” discharge and vent
-
Built-in anti float collar prevents basin from floating
-
Molded torque stops prevent pump from turning
-
Integrated 360° lifting handle
-
45 gallon capacity
BASIN COVER
-
18” Premium cover
-
18” Premium split lid cover
CHECK VALVE FEATURES
-
Full flow design - 99529
-
Heavy duty rubber boots
-
Stainless steel clamps
-
Full flow design
-
Weighted flapper valve
-
2" connections
Technical Specifications
HORSEPOWER | 1/2 |
AMPS | 12 |
CONSTRUCTION | Stainless Steel / Cast Iron |
SWITCH TYPE | Vertical |
DISCHARGE SIZE | 2“ |
DISCHARGE TYPE | Side |
CORD LENGTH | 15’ |
SOLIDS HANDLING | 2” |
IMPELLER TYPE | Thermoplastic, Non-Clogging Vortex |
SWITCH ON POINT | 10“ |
SWITCH OFF POINT | 4” |
LIQUID TEMP. RANGE | 35° F - 120° F |
PUMPS DOWN TO | 3” From Surface When Used As Utility |
WARRANTY | 1 Year |
